EVO

Introducing the Fox ESS EVO Series: Your Next-Generation, All-in-One Energy Storage Solution

Discover the Fox ESS EVO Series, a next-generation energy storage system for a seamlessly integrated, truly all-in-one solution. Designed with a sleek, minimalist aesthetic, the EVO Series facilitates effortless one-step installation, embodying a 'less is more' philosophy.

Experience Reliable and Efficient Power Management

Utilising robust LFP technology, the system provides a high DOD of 95% and an impressive 6000 cycle life. Benefit from high energy conversion efficiencies, including a Max Conversion Efficiency of 97.6%.

The EVO Series is built for independence and reliability, offering Off-Grid capability and double off-grid backup capability. It supports 4ms parallel off-grid switching and can handle challenging loads with a 200% overload capacity for 10 seconds. Parallel operation is supported for up to 3 units. An integrated EPS function ensures backup power is available, with support for dual EPS expansion.

Safety is a core component, with comprehensive integrated protection features such as anti-islanding protection, residual current monitoring, AC short-circuit protection, AC overcurrent/overvoltage protection, a DC Switch, and AFCI protection. The system complies with a wide range of safety, EMC, grid regulation, and battery standards.

Built tough to perform in various conditions, the system boasts an IP66 rated protection degree and operates across a wide temperature range of -20°C to 55°C. Noise emissions are kept low, averaging <40dB and peaking at <45dB. The design is versatile, allowing for either floor-mounted or wall-mounted installation.

Stay informed and in control with the FoxCloud V2.0 Advanced System Monitoring. You can monitor system performance via the mobile app, using various communication interfaces including WiFi, LAN, 4G, and Ethernet.

Specifications
