Ideal HP290 DHW Pre-Plumbed Slimline Cylinder 150L and Control Box 1-Zone
HP290 Pre-Plumbed Cylinder
Log in or register for trade discounts!
Quantity:BUY!
tell me more
These Ideal pre-plumbed cylinders are designed to install with an Ideal HP290 air source heat pump quickly neatly and without any hold ups.
This top-quality product saves valuable installation time, helps prevent installation faults, and is space-efficient and neat. There is also the additional benefit of a 25 Year Manufacturing Warranty on the Stainless Steel Vessel and 2 Years parts and labour warranty on components.
Cylinder Specifications
Capacity:
145L
Weight (empty):
46kg
Weight (full):
192kg
Overall Height:
1598mm
Cylinder Height:
1519mm
Width:
581mm
Depth:
606mm
Diameter:
475mm
Primary Heat Exchanger Surface Area:
1.8m²
Product Details
Product code
240127
Standing heat loss
50W/h
Re-heat time 10 degC to 50 degC**
22.26mins
Energy Efficiency Class
B
Included Components
- Control Box
- Heat Pump Filter
- DHW 3-port Valve
- P&T Valve
- High Temp Cut Out
- Expansion Vessel
- Pressure Gauge
- Automatic Air Vent(s)
- Isolation Valves
- 3kW Immersion
- Flow & Return Thermistors
- DHW Thermistor
- Outdoor Sensor
Key Features
- Industry-leading reheat times
- 25-year warranty on vessel
- Fully pre-plumbed and pre-wired
- Factory-fitted control box
- Highly efficient multi-coil heat exchanger
- Halo Lite RF Compatible
- Made in the UK
**Heat Up Time, HWA Heat Pump Test 002:2020 (flow rate 0.42l/s and flow temperature of 55°C).
